SERVICE GASKET KIT GENUINE ALLISON TRANSMISSION 29547606

SERVICE GASKET KIT GENUINE ALLISON TRANSMISSION 29547606

29547606

£449.98
£449.98
Ex VAT Sale Sold out

16 in stock

SERVICE GASKET KIT GENUINE ALLISON TRANSMISSION 29547606

Product Details

  • All-inclusive complete kit containing all the required seals, O-rings, and gaskets needed to seal the transmission and complete the transmission gasket & seal service.
  • Prevents leaks
  • Used on all transmissions equipped with Allison 4th Generation Controls
  • Allison Genuine Parts™
  • Manufactured by Allison
    8661834 1   Screen, Solenoid
    12129390 1   O-Ring, 31.42 mm ID
    23043446 1   O-ring, 8.9 mm ID
    23049056 6   Bolt, M10 x 1.5 x 15
    24235861 1  view history for 24235861Seal, Selector Shaft
    29503381 3   O-ring, 10.8 mm ID
    29503382 3   O-ring, 14.0 mm ID
    29531293 1   Sealring, C1 Piston ID

    		29534145 3   O-ring, Speed Sensor
    29534894 1   Sealring, C5 Piston OD
    29535518 3  view history for 29535518O-ring, Solenoid, 13.0 mm ID
    29536379 1   Seal Assembly, Oil
    29536406 1   Sealring Kit, Butt Joint
    29536478 1   Gasket, Main Housing/Separator Plate
    29536834 2  view history for 29536834Seal, Fill Tube
    29536858 1   Sealring, C5 Piston ID
    29536941 1  view history for 29536941Gasket, Rear Cover
    29537620 1  view history for 29537620O-ring, 145.72 mm ID
    29538940 3   Sealring.
    29540130 1  view history for 29540130Gasket, Converter Housing/Separator Plate
    29542697 1   Screw, Socket Hd Cap, M5 x 0.8 x 20
    29542808 1   Sealring, C2 Piston ID
    29542809 1   Sealring, C2 Piston
    29542812 1   Sealring, C1 Housing OD
    29542815 1   Piston, C1 Balance
    29542976 1   O-Ring, Solenoid
    29545377 1  view history for 29545377O-Ring, C1/C2
    29546682 1  view history for 29546682Seal Assembly, Oil
    29546697 2   Piston, C3/C4
    29546762 1   O-ring, Main Regulator Stop
    29546763 3   Sealring Kit, Double Lap Joint, 74 mm
    29549684 1  view history for 29549684Gasket, Oil Pan
    29555896 10  view history for 29555896Seal, Bolt.
    29558601 3  view history for 29558601Sealring.
    29561637 2  view history for 29561637Gasket, PTO Cover 15-1K2K-19.
    29562692 1   Sealring, C1 Piston
    29565365 1  view history for 29565365Seal, Oil Pan Drain Plug

  • BENEFITS

    • All-inclusive kit
    • Forms a tight seal around a component
    • Prevents leaks
    • Proper operating pressure
    • Allison Genuine Parts™
    • Built to original manufacturer specifications

Genuine Allison Transmission product.
Mitchell Powersystems are an authorised Allison Transmission distributor for the UK.
Please message us with your transmission serial number to check compatibility.
